有朋友今天這樣問了不銹鋼過濾網的大目和中等目各是多少？今天盛邦絲網廠就不銹鋼過濾網目數是多少進行簡單的介紹一下:不銹鋼過濾網1目-3200目不銹鋼篩網的大目數是3200目。
不銹鋼過濾網性能有4點：
具耐酸、耐堿、耐溫、耐磨等性能
不銹鋼過濾網主要用途：
用于礦業、石油、化工、食品、醫藥、機械制造等行業。
擠出機料簡前由篩板支撐的不同網目的金屬絲網組，其作用是過濾熔融料流和增加料流阻力，借以濾去機械雜質和提高混煉或塑化的效果。
過濾網分為 紡織纖維濾網和五金等,先在國內生產纖維過濾網的是 以臺河北省安平縣盛邦篩網廠為代表的 盛邦篩網廠的聚集地,還有就是安平的五金篩網,都是非常有名氣的. (河北省的安平縣,是過濾網篩網產品類生產基地,早史建于1988年,河北安平縣盛邦絲網廠就是其中的篩網廠家之一!)
安裝過濾網的機器成為過濾器，用來過濾自然水和食物.
不銹鋼過濾網標準：(在篩網產品使用過程中怎樣安全安裝絲網也是有必要了解的參考<<怎樣安裝操作不銹鋼絲網?>>)
JB/T 10718-2007
NF F13-825-1992
NF F13-825-1992
DIN 87154-1954
過濾網特點： 直接過濾，工藝簡單，透氣性好，精度均勻穩定，不泄漏，再生性能好、再生速度快、安裝方便、效率高、使用壽命長。
不銹鋼篩網參數規格:
|
目數 |
絲徑 |
孔徑 |
開孔面積 |
網重（磅） /100 平方英尺 |
||
| 英寸 | 毫米 | 英寸 | 毫米 | |||
|
1x1 |
.080 |
2.03 |
.920 |
23.37 |
84.6 |
41.1 |
|
2X2 |
.063 |
1.60 |
.437 |
11.10 |
76.4 |
51.2 |
|
3X3 |
.054 |
1.37 |
.279 |
7.09 |
70.1 |
56.7 |
|
4X4 |
.063 |
1.60 |
.187 |
4.75 |
56.0 |
104.8 |
|
4X4 |
.047 |
1.19 |
.203 |
5.16 |
65.9 |
57.6 |
|
5X5 |
.041 |
1.04 |
.159 |
4.04 |
63.2 |
54.9 |
|
6X6 |
.035 |
.89 |
.132 |
3.35 |
62.7 |
48.1 |
|
8X8 |
.028 |
.71 |
.097 |
2.46 |
60.2 |
41.1 |
|
10X10 |
.025 |
.64 |
.075 |
1.91 |
56.3 |
41.2 |
|
10X10 |
.020 |
.51 |
.080 |
2.03 |
64.0 |
26.1 |
|
12X12 |
.023 |
.584 |
.060 |
1.52 |
51.8 |
42.2 |
|
12X12 |
.020 |
.508 |
.063 |
1.60 |
57.2 |
31.6 |
|
14X14 |
.023 |
.584 |
.048 |
1.22 |
45.2 |
49.8 |
|
14X14 |
.020 |
.508 |
.051 |
1.30 |
51.0 |
37.2 |
|
16X16 |
.018 |
.457 |
.0445 |
1.13 |
50.7 |
34.5 |
|
18X18 |
.017 |
.432 |
.0386 |
.98 |
48.3 |
34.8 |
|
20X20 |
.020 |
.508 |
.0300 |
.76 |
36.0 |
55.2 |
|
20X20 |
.016 |
.406 |
.0340 |
.86 |
46.2 |
34.4 |
|
24X24 |
.014 |
.356 |
.0277 |
.70 |
44.2 |
31.8 |
|
30X30 |
.013 |
.330 |
.0203 |
.52 |
37.1 |
34.8 |
|
30X30 |
.012 |
.305 |
.0213 |
.54 |
40.8 |
29.4 |
|
30X30 |
.009 |
.229 |
.0243 |
.62 |
53.1 |
16.1 |
|
35X35 |
.011 |
.279 |
.0176 |
.45 |
37.9 |
29.0 |
|
40X40 |
.010 |
.254 |
.0150 |
.38 |
36.0 |
27.6 |
|
50X50 |
.009 |
.229 |
.0110 |
.28 |
30.3 |
28.4 |
|
50X50 |
.008 |
.203 |
.0120 |
.31 |
36.0 |
22.1 |
|
60X60 |
.0075 |
.191 |
.0092 |
.23 |
30.5 |
23.7 |
|
60X60 |
.007 |
.178 |
.0097 |
.25 |
33.9 |
20.4 |
|
70X70 |
.0065 |
.165 |
.0078 |
.20 |
29.8 |
20.8 |
|
80X80 |
.0065 |
.165 |
.0060 |
.15 |
23.0 |
23.2 |
|
80X80 |
.0055 |
.140 |
.0070 |
.18 |
31.4 |
16.9 |
|
90X90 |
.005 |
.127 |
.0061 |
.16 |
30.1 |
15.8 |
|
100X100 |
.0045 |
.114 |
.0055 |
.14 |
30.3 |
14.2 |
|
100X100 |
.004 |
.102 |
.0060 |
.15 |
36.0 |
11.0 |
|
100X100 |
.0035 |
.089 |
.0065 |
.17 |
42.3 |
8.3 |
|
110X110 |
.0040 |
.1016 |
.0051 |
.1295 |
30.7 |
12.4 |
|
120X120 |
.0037 |
.0940 |
.0064 |
.1168 |
30.7 |
11.6 |
|
150X150 |
.0026 |
.0660 |
.0041 |
.1041 |
37.4 |
7.1 |
|
160X160 |
.0025 |
.0635 |
.0038 |
.0965 |
36.4 |
5.94 |
|
180X180 |
.0023 |
.0584 |
.0033 |
.0838 |
34.7 |
6.7 |
|
200X200 |
.0021 |
.0533 |
.0029 |
.0737 |
33.6 |
6.2 |
|
250X250 |
.0016 |
.0406 |
.0024 |
.0610 |
36.0 |
4.4 |
|
270X270 |
.0016 |
.0406 |
.0021 |
.0533 |
32.2 |
4.7 |
|
300X300 |
.0051 |
.0381 |
.0018 |
.0457 |
29.7 |
3.04 |
|
325X325 |
.0014 |
.0356 |
.0017 |
.0432 |
30.0 |
4.40 |
|
400X400 |
.0010 |
.0254 |
.0015 |
.370 |
36.0 |
3.3 |
|
500X500 |
.0010 |
.0254 |
.0010 |
.0254 |
25.0 |
3.8 |
|
635X635 |
.0008 |
.0203 |
.0008 |
.0203 |
25.0 |
2.63 |
| 目數 |
絲徑 |
絕對過濾值μm |
名義過濾值 μm |
|
8X85 |
.014X.0126 |
318 － 340 |
250 － 255 |
|
12X64 |
.024X.0165 |
270 － 285 |
200 － 205 |
|
14X88 |
.020X.013 |
225 － 245 |
150 － 155 |
|
20X150 |
s.0098X.007 |
155 － 165 |
100 － 105 |
|
24X100 |
.015X.010 |
115 － 125 |
80 － 85 |
|
30X150 |
.009X.007 |
95 － 100 |
65 － 70 |
|
40X200 |
.007X.0055 |
65 － 70 |
55 － 60 |
|
50X250 |
.0055X.0045 |
55 － 60 |
40 － 45 |
|
80X400 |
.0049X.0028 |
43 － 48 |
35 － 40 |
不銹鋼絲網-斜紋－密紋編織參數：
|
對于不銹鋼過濾網參數和其目數基本就這么多!具體的其實還是根本行業需求不同和實際場地不同而制定不同的篩網目數要求!
